CF220b-2505-C-50-Fw Long Stroke Direct Coupling Screw Linear Module Cartesian Coordinate Manipulator with High Precision
5.0InStock Source-listed auditby Lishui Chuangfeng Technology Co., Ltd
₹25,050≈ $300 · indicative, confirm with supplier
Payment
T/T
Port
Ningbo, China
Incoterms
CIF, FOB, CFR, EXW
Supplier information
Lishui Chuangfeng Technology Co., Ltd
Zhejiang, China
Audited supplier
Description
CF220b-2505-C-50-Fw Long Stroke Direct Coupling Screw Linear Module Cartesian Coordinate Manipulator with High Precision, Find Details and Price about Linear Module Industrial Robot Arm from CF220b-2505-C-50-Fw Long Stroke Direct Coupling Screw Linear Module Cartesian Coordinate Manipulator with High Precision - Lishui Chuangfeng Technology Co., Ltd
Specifications
Reach50mm-2000mm
OriginLishui, Zhejiang, China
SensorPm-T45
HS Code8479501000
Model NO.CF220B-2505-C-50-FW
TrademarkCFR
Belt Speed250-1562mm/S
Screw Lead5mm, 10mm, 25mm, 32mm, Optional
Package Size1800.00cm * 250.00cm * 170.00cm
Load Capacity140kg Horizontally, 50kg Vertically
SpecificationWidth: 220MM
Screw Diameter25mm or 32mm
Effective Stroke50mm-2000mm Optional
Payload Capacity140kg Horizontally, 50kg Vertically
Transport PackageSpecial Carton Packaging
Production Capacity10000sets/Year
Package Gross Weight20.000kg
Linear Guide Rail Configuration2 Pieces of EGR25 Guide Rails, 4 Pieces of Egh25ca
